Discover the superiority of MTSP compressors and dry-running rotary vane vacuum pumps: they are incredibly powerful, dependable, and small.
They are perfect for industrial applications requiring quick, clean vacuum or compressed air because they don’t require lubrication.
Gain from increased performance and availability as a result of ongoing product improvement. Expect unmatched durability from MTSP because of its sturdy design and lifetime lubricated bearings.
| Model | MTSP010 | MTSP016 | MTSP025 | MTSP040 |
|---|---|---|---|---|
| Flow Rate 50Hz m3/h | 10 | 16 | 25 | 40 |
| Flow Rate 60Hz m3/h | 12 | 19.2 | 30 | 48 |
| Vacuum mbar | 150 | 150 | 150 | 150 |
| Motor Power 50Hz KW | 0.37 | 0.55 | 0.75 | 1.25 |
| Motor Power 60Hz KW | 0.44 | 0.66 | 0.9 | 1.5 |
| Motor Speed 50Hz | 1420 | 1420 | 1420 | 1420 |
| Motor Speed 60Hz | 1700 | 1700 | 1700 | 1700 |
| Noise | 60 | 61 | 62 | 67 |
| Weight | 15 | 22 | 28 | 39 |
Mechvac’s dry rotary vane vacuum pumps are engineered for reliable, clean, oil-free, and energy-efficient vacuum generation across demanding industrial applications.
They are designed for oil-free operation that delivers consistent performance with compact installation, reduced maintenance, and dependable operation in environments where contamination-free vacuum is essential.
Mechvac’s dry rotary vane vacuum pumps are used in packaging and thermoforming, CNC routing, pharmaceuticals, and vacuum conveying. Our rotary vane pumps offer a practical and high-performance solution for continuous industrial use.
Mechvac’s dry rotary vane vacuum pumps are engineered to deliver reliable and clean vacuum performance for demanding industrial applications where reduced maintenance, operation consistency, and oil-free vacuum generation are critical.
These industrial rotary vane pumps are designed for dry-running operation, and they eliminate the need for oil within the compression chamber. Sealing performance is achieved through engineered internal clearances and self-lubricating vane materials. This makes them an efficient solution for applications that require cleaner processing environments and simplified maintenance.
Built for modern industrial performance, Mechvac’s dry rotary vane vacuum pumps combine compact construction with dependable vacuum output, making them suitable for both standalone machinery integration and centralized vacuum systems.
At Mechvac, we understand that industrial rotary vane pumps must perform consistently under continuous operational demands, so our pumps are designed with durability at every level.
The internal construction features high-strength stator and end plate materials engineered for structural integrity under challenging industrial conditions. Rotor construction is designed to provide improved wear resistance and high mechanical precision during continuous operation.
This supports reliable long-term performance even in demanding environments.
Our rotary vane vacuum pumps also have composite vane technology, which further strengthens pump reliability and offers smoother operation, improved durability, and reduced wear compared to standard vane materials.
This helps in extending service life while minimizing maintenance interruptions.
The dry rotary vane pumps have sealed, self-lubricated bearings , which reduce routine maintenance requirements and support reliable long-term operation.
This makes the dry rotary vane vacuum pumps from Mechvac a practical choice for facilities focused on uptime and operational efficiency.
| Model | Pumping Speed | Ultimate Pressure | Motor Power | Pumping Speed | Noise Level 50/60Hz | Weight | Dimensions | |||
|---|---|---|---|---|---|---|---|---|---|---|
| 50 Hz | 60 Hz | 50Hz | 60Hz | 50Hz 3ph/1ph | 60Hz 3ph/1ph | |||||
| MTD 8 | 8 m³/h | 9.6 m³/h | 150 mbar | 0.37 kW | 0.44 kW | 1420 rpm / 1380 rpm | 1700 rpm / 1630 rpm | 58 dB | 13 kg | 314×140×177 mm |
| MTD 10 | 10 m³/h | 12 m³/h | 150 mbar | 0.37 kW | 0.44 kW | 1420 rpm | 1700 rpm | 60 / 62 dB | 15 kg | 430×205×198 mm |
| MTD 16 | 16 m³/h | 19.2 m³/h | 150 mbar | 0.55 kW | 0.66 kW | 1420 rpm | 1700 rpm | 61 / 64 dB | 22 kg | 450×225×215 mm |
| MTD 25 | 25 m³/h | 30 m³/h | 150 mbar | 0.75 kW | 0.9 kW | 1420 rpm | 1700 rpm | 62 / 67 dB | 28 kg | 502×252×292 mm |
| MTD 40 | 40 m³/h | 48 m³/h | 150 mbar | 1.25 kW | 1.5 kW | 1420 rpm | 1700 rpm | 67 / 72 dB | 39 kg | 570×270×292 mm |
| MTD 60 | 60 m³/h | 72 m³/h | 150 mbar | 2.2 kW | 2.6 kW | 1420 rpm | 1700 rpm | 71 / 73 dB | 70 kg | 729×340×340 mm |
| MTD 80 | 80 m³/h | 96 m³/h | 150 mbar | 2.2 kW | 2.6 kW | 1420 rpm | 1700 rpm | 72 / 75 dB | 70 kg | 729×340×340 mm |
| MTD 100 | 100 m³/h | 120 m³/h | 150 mbar | 3 kW | 3.6 kW | 1420 rpm | 1700 rpm | 75 / 76 dB | 105 kg | 870×460×382 mm |
| MTD 140 | 140 m³/h | 168 m³/h | 150 mbar | 4 kW | 4.8 kW | 1420 rpm | 1700 rpm | 77 / 79 dB | 115 kg | 870×460×382 mm |
| MTD 160 | 160 m³/h | 192 m³/h | 150 mbar | 5.5 kW | 6.6 kW | 1420 rpm | 1700 rpm | 77 / 79 dB | 126 kg | 923×460×382 mm |
| MTD 200 | 200 m³/h | 240 m³/h | 200 mbar | 4 kW | 4.8 kW | 960 rpm | 1150 rpm | 75 / 77 dB | 258 kg | 1210×612×426 mm |
| MTD 250 | 250 m³/h | 300 m³/h | 200 mbar | 5.5 kW | 6.6 kW | 960 rpm | 1150 rpm | 81 dB | 280 kg | 1210×612×426 mm |
| MTD 360 | 351 m³/h | / | 250 mbar | 11 kW | / | 1430 rpm | / | 80.5 dB | 312 kg | 1210×612×426 mm |
| MTD 400 | 400 m³/h | 480 m³/h | 350 mbar | 11 kW | 13.2 kW | 960 rpm | 1150 rpm | 81 dB | 320 kg | 1210×612×527 mm |
Ensures reliable vacuum generation for packaging systems requiring clean and consistent evacuation.
Suitable for light-duty vacuum drying applications with controlled vapor loads.
Reliable vacuum generation for removing trapped gases and air pockets in industrial processing applications.
Enables fast and stable evacuation for industrial chambers, packaging systems, and process equipment.
Provides dependable suction performance for vacuum lifting, pick-and-place, and automated material handling systems.
Suitable for contamination-sensitive battery production environments requiring clean, dry vacuum systems.
Ideal for thermoforming, vacuum pressing, and lamination applications requiring consistent vacuum pressure.
Supports efficient transfer of powders, granules, and lightweight industrial materials.
Helps maintain controlled vacuum conditions for precision casting and finishing applications.
Used in vacuum-assisted filtration processes requiring dependable and uninterrupted vacuum generation for clean and dry filtration processes .
Supports vacuum-dependent processes in solar, wind, and clean energy manufacturing environments.
A dependable industrial vacuum source for centralized plant utilities and general-purpose vacuum requirements.
Suitable for non-critical clean vacuum applications in medical and laboratory support systems.
Reliable vacuum support for testing, prototyping, laboratory processes, and controlled experimental applications.
The right vacuum pump depends on your process requirements, operating environment and maintenance expectations.
Oil-sealed rotary vane vacuum pumps are suitable for applications requiring deeper vacuum levels while dry rotary vane vacuum pumps are ideal for cleaner operations, lower maintenance and simplified system management.
100% Oil-Free Operation – No risk of oil contamination in critical processes
Cleaner Vacuum Performance – Ideal for sensitive industrial applications
Lower Maintenance Needs – No oil changes, filtration, or lubricant management
Compact Footprint – Easy integration into space-constrained systems
Fast, Reliable Vacuum Generation – Consistent performance for continuous processes
Low Noise & Vibration – Smoother operation for industrial environments
Reduced Operating Costs – Lower servicing and maintenance overheads
Simplified System Management – Less complexity compared to oil-sealed alternatives
Dry rotary vane vacuum pumps are best suited when clean operation and low maintenance matter more than ultra-deep vacuum levels.
Introducing the ultimate in precision vacuum engineering: the Mechvac RD oil sealed double stage vane pumps.
These pumps are multifunctional powerhouses that are trusted and used in both industrial production and cutting edge research.
They easily integrate into intricate pump configurations with high vacuum or Roots pumps.
Mechvac RD pumps are engineered to overcome atmospheric pressure and offer unmatched vacuum performance.
The Mechvac MT Series represents the pinnacle of vacuum pump technology.
This series, which combines cutting edge direct seal rotary vane technology with expert craftsmanship, is the pinnacle of excellence, fusing cutting edge innovation with demand driven design improvements.
Made from premium raw materials, every essential part guarantees that the M Series performs exceptionally well: reaching very high vacuum levels, minimizing noise and vibration, optimizing efficiency, guaranteeing unwavering reliability, and making installation and maintenance procedures easier.
